| DIMENSION | 2.67'' x 6.85'' x 1.67'' (6.77 x 17.40 x 4.23 cm) |
|---|---|
| DISPLAY SIZE | 1.5"W x 2.5"H (3.8 x 6.3 cm); 3" diag (7.6 cm) |
| DISPLAY RESOLUTION | 240 x 400 pixels |
| DISPLAY TYPE | transflective, 65K color TFT |
| WEIGHT |
9.95 oz (282g) with batteries |
| WATERPROOF | IPX7 |
| BATTERY TYPE | 2 AA batteries (not included); NiMH or Lithium recommended |
| BATTERY LIFE |
up to 19 hours |
| MIL-STD-810 | yes (thermal, shock, water); bare unit only |
| INTERFACE | high speed microUSB and NMEA 0183 compatible |
| MEMORY/HISTORY | 8 GB (user space varies based on included mapping on sc version) |
| PRELOADED MAPS |
Available on sc version only |
|---|---|
| ABILITY TO ADD MAPS | |
| BASEMAP | |
| AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES | Yes (with optional mapping for detailed roads) |
| MAP SEGMENTS | 15000 |
| INCLUDES DETAILED HYDROGRAPHIC FEATURES (COASTLINES, LAKE/RIVER SHORELINES, WETLANDS AND PERENNIAL AND SEASONAL STREAMS) | Yes (downloadable from Garmin Express™) |
| INCLUDES SEARCHABLE POINTS OF INTERESTS (PARKS, CAMPGROUNDS, SCENIC LOOKOUTS AND PICNIC SITES) | Yes (downloadable from Garmin Express™) |
| DISPLAYS NATIONAL, STATE AND LOCAL PARKS, FORESTS, AND WILDERNESS AREAS | Yes (downloadable from Garmin Express™) |
| EXTERNAL MEMORY STORAGE | yes (32 GB max microSD™ card, not included) |
| WAYPOINTS/FAVORITES/LOCATIONS | 10000 |
| TRACKS | 250 |
| NAVIGATION TRACK LOG | 20,000 points, 250 saved gpx tracks, 300 saved fit activities |
| NAVIGATION ROUTES | 250, 250 points per route; 50 points auto routing |
| RINEX LOGGING |
