Name: Harken 500 Big Boat 3" Sheave Replacement
Brand: Pacific Sailboat Supply
SKU: 103200
Price: 233.95 USD
Availability: InStock

HARKEN

Big Boat Sheaves

Big Boat sheaves are available for special applications, as well as for replacement sheaves in Big Boat blocks. Made of Hard Lube-anodized 6061-T6 aluminum, sheaves feature Torlon® rollers to carry high radial loads and carbon-black Delrin® balls to support side loads and provide UV protection. (Delrin® is a registered trademark of E. I. du Pont de Nemours and Company or its affiliates. Torlon® is a registered trademark of Solvay Advanced Polymers.)

Select sheaves based on load-carrying capability. Installation requires clamping or securing inner race.

Use for:

Mainsheets
Spinnaker sheets
Afterguy/foreguy
Foot blocks

Mfg No.	Sheave Diameter	Width	Max Line Diameter	Center Pin Diameter	Fasteners	MWL¹	BL²
500	3" (76mm)	7/8" (22mm)	9/16" (14mm)	3/8" (10mm)	3/8" (10mm)	4950 Lbs (2245kg)	9900 Lbs (4490kg)²
